TIP CUT-0401 Auto Sheet Length & Squaring Upgrade

TIP_CUT-0401_Auto Sheet Length & Squaring Upgrade

Machine Model for Improvement

All Folio-Size Sheeters type SHM

Description of Improvement

This upgrade is part of the Technical Improvement Program (TIP); it is designed as a direct substitute for the obsolete SHM Sheet Length and Squaring Controller. It performs all of the functionality of the older controller as well as some new functionality, not available with the older controller.

This upgrade is designed to use all existing machine mounted hardware wherever possible. The squaring position transducer, draw drum encoder, knife marker, squaring and length motors, selector switches, and pushbuttons remain the same. These devices plug into the same receptacles on the newer unit as they did on the older unit.

The only piece of existing hardware that is not used is the thumbwheel (or edge) switches. These have been replaced with a 3.8” color TFT touch screen. Through this device the operator enters the sheet length (selectable, millimeters or inches), performs diagnostics, and calibrates the unit.

Benefits

  • Thumbwheels are not used anymore to enter sheet length
  • Digital operator interface to enter sheet length and removal of old thumbwheel system
  • PLC controller for advanced operation with easy set up and diagnostics
